RG‑RAP72 Wi‑Fi 7 Access Point – 2.5 GbE + 4 × 1 GbE, 3600 Mbps, PoE+

High-speed Wi‑Fi 7 access point with up to 3.6 Gbps aggregate throughput, 1×2.5 GbE uplink + 4×1 GbE ports, dual-stream MIMO antennas, and PoE power. Supports 8 SSIDs, VLAN, WPA3 security, and Ruijie Cloud/Web/SNMP management—ideal for modern offices, hotels, and schools.

Add to quote

  • Next‑Gen Wi‑Fi 7 Performance
    Supports IEEE 802.11be with dual-band operation and data rates up to 3,600 Mbps (2.4 GHz: up to 688 Mbps; 5 GHz: up to 2,882 Mbps) on 2×2 MIMO.

  • 🔗 Multi-Gigabit Wired Ports
    Features one 2.5 GbE RJ45 PoE+ uplink and four Gigabit RJ45 LAN ports (one supports PoE out), enabling high-capacity backhaul and IoT device connectivity.

  • Smart RF & Mesh Networking
    Includes MRU, Multi-Link Operation (MLO), Wi‑Fi Intelligent Optimization (WIO), and support for 802.11k/v/r for seamless roaming. Self‑organizing mesh network simplifies expansion.

  • Enterprise‑Grade Security & VLAN Support
    Offers WPA3-SAE, WPA2/WPA3 Mixed Mode, 802.1X authentication, VLAN tagging (802.1Q), client isolation, and ACL control for secure multi-tenant environments.

  • Flexible Management Options
    Manage remotely via cloud, Web UI, mobile app, or SNMP v1/2c/3. Offers zero-touch setup, troubleshooting, and diagnostics.

  • Sleek & Quiet Design
    Compact (129 × 86 × 24 mm), fanless design for silent operation. Ceiling or wall mountable with PoE power simplifies deployment.

Categories: , Brand:

Technical Specifications

Feature Specification
Model RG‑RAP72
Wi‑Fi Standard 802.11a/b/g/n/ac/ax/be
Radio Streams 2×2 MIMO (2.4 GHz), 2×2 MIMO (5 GHz)
Max Data Rate 3,600 Mbps (688 Mbps @2.4 GHz, 2,882 Mbps @5 GHz)
Ethernet Ports 1×2.5 GbE PoE+ uplink; 4×1 GbE ports (1 × PoE‑out)
PoE Input/Output IEEE 802.3at PoE+ (input); PoE‑out via LAN port
SSID / Client Support Up to 8 SSIDs; 110 recommended clients, 512 max
Security Features WPA3‑SAE, WPA2‑Enterprise, OWE, 802.1X, client isolation
VLAN 802.1Q support, port-based VLANs
Roaming & Mesh 802.11k/v/r, MRU, MLO, WIO, Mesh support
Management Interfaces Cloud, Web UI, Mobile App, SNMP v1/2c/3
Power Consumption < 30 W
Operating Environment 0 °C–40 °C; 5–95% RH (non-condensing)
Dimensions & Weight 129 × 86 × 24 mm; ~270 g (excluding mount)
Certifications CE, RoHS, FCC, ISED, cTUVus
