HPE ProLiant DL20 Gen10 Plus – 1U Xeon E‑2300 Server, up to 128 GB DDR4, PCIe 4.0
HPE ProLiant DL20 Gen10 Plus – 1U Xeon E‑2300 Server, up to 128 GB DDR4, PCIe 4.0 - Image 2
HPE ProLiant DL20 Gen10 Plus – 1U Xeon E‑2300 Server, up to 128 GB DDR4, PCIe 4.0 - Image 3

HPE ProLiant DL20 Gen10 Plus – 1U Xeon E‑2300 Server, up to 128 GB DDR4, PCIe 4.0

Versatile 1U server with single-socket Intel Xeon E‑2300 up to 8 cores, support for up to 128 GB DDR4, dual hot‑plug LFF or up to 6 SFF drives, dual PCIe 4.0 slots, and HPE iLO 5 remote management—ideal for SMB, retail, or remote deployments.

  • Form Factor: 1U Rack Server
  • Supported Processor: Intel Xeon E-2300 series
  • Total Memory Slots: 4 DIMMs
  • PCI slots: 2 PCIe 4.0 slots
  • Max Memory: 128GB
  • Max Cores: 8 Cores
  • Assured Warranty : 3 Years
  • Instant Shipping
  • 24/7 Technical Support Assistance

Add to quote

  • Single-Socket Xeon Performance
    Supports Intel Xeon E-2300 series (4–8 cores, up to 3.8 GHz), offering a cost-effective balance of compute power and efficiency.

  • Memory Flexibility
    Four DDR4 UDIMM slots support up to 128 GB ECC memory (2666–3200 MT/s), delivering reliable RAM bandwidth for virtualization and general workloads.

  • Configurable Storage Bays
    Choose from 2 LFF hot-plug, 4 + 2 SFF hot-plug, or 6 SFF hot-swap drive layouts—perfectly adaptable to NAS, hybrid, or all-flash storage needs.

  • PCIe 4.0 Expansion
    Rear-mounted slots offer 1× x8 low-profile and 1× x16 half-length PCIe Gen4, enabling easy upgrades for networking, RAID controllers, or accelerators.

  • Security & Management
    HPE iLO 5 enables remote administration, with robust firmware protection (silicon root of trust), secure recovery, and optional TPM & dedicated iLO port kits.

  • Efficient Power & Cooling
    Compact 15″ chassis with energy-optimized thermal design; ships with a 290 W Platinum non-redundant PSU, upgradeable to redundant 500 W or 800 W flex slot options. ENERGY STAR certified with power capping and variable fan control.

Category: Brand:

Key Specifications

Feature Specification
Model HPE ProLiant DL20 Gen10 Plus
Form Factor 1U, short-depth rack (≈382 × 434 × 44 mm)
Processor Intel Xeon E‑2300 Series or Pentium (4C–8C, up to 3.8 GHz)
Memory 4× DDR4 ECC UDIMM slots, up to 128 GB (2666/3200 MT/s)
Storage Options 2× LFF hot-plug or 4+2 SFF or 6× SFF hot-swap
PCIe Slots 1× Gen4 x8 low-profile, 1× Gen4 x16 half-length
Network 2× 1 GbE embedded; FlexibleLOM/PCIe options available
Management HPE iLO 5 (option for advanced remote management)
Power Supply 290 W Platinum PSU; optional 500 W or 800 W flex-slot
Security Features Silicon root of trust, secure recovery, TPM, firmware validation
Thermal & Power Efficiency Variable fan speed, power capping, ENERGY STAR certified
