24-Port Gigabit PoE+ Cloud‑Managed Switch w/ 4×10G SFP+ – 370 W PoE Budget

Elevate your network with this Layer 2 managed switch featuring 24 gigabit PoE+ ports, 4 10G SFP+ uplinks, and a powerful 370 W PoE budget. It supports cloud-based management, VLANs, IGMP snooping, and robust security—ideal for surveillance systems, Wi‑Fi APs, VoIP phones, and more.

Add to quote

Engineered for demanding SMB and enterprise deployments, this switch delivers:

⚡ Scalable Power & Connectivity

  • 24×10/100/1000 Mbps PoE+/PoE++ RJ45 ports (up to 30 W each; total 370 W)

  • 4×10 Gigabit SFP+ uplinks for high-speed backbone integration

🚀 High-Performance Switching

  • 128 Gbps switching capacity & ~96 Mpps forwarding rate

  • 16,000 MAC address table and support for up to 4094 VLANs

🔒 Advanced Layer 2 Features & Security

  • VLAN segmentation, link aggregation (LAG/LACP), IGMP snooping, loop protection

  • Multiple security policies, port-based ACLs, DHCP snooping, IP-MAC binding

  • Built-in ±6 kV surge protection on ports

☁️ Smart Cloud Management

  • Zero‑touch provisioning via QR code, remote configuration, monitoring, and firmware updates through Ruijie Cloud platform

  • Ideal for IP camera networks, remote sites, and automated maintenance

🔧 Reliable Hardware Build

  • Compact 1U rack-mount chassis (440 × 357.6 × 43.6 mm; ~4.75 kg) with quiet fan cooling

  • Operating temperature range 0 °C–50 °C, MTBF >200,000 h; backed by a 5-year warranty

Categories: , Brand:

Technical Specifications

Feature Specification
Ports 24×1 Gb PoE+ (802.3at), 4×10 Gb SFP+
PoE Budget 370 W total
Switching Capacity 128 Gbps
Forwarding Rate ~96 Mpps
MAC Table 16,000 entries
VLAN IDs Up to 4,094
Surge Protection ±6 kV on data & PSU ports
MTU (Jumbo Frames) 9,216 bytes
QoS / LAG VLAN, QoS, LAG/LACP
Security Features ACLs, 802.1X, DHCP snooping, IP-MAC binding
Management Web, SNMP, Cloud (Ruijie), mobile app
Cooling & Noise 1×fan, <45 dB
Power Supply Fixed 100–240 V AC
Dimensions (W×D×H) 440 mm × 357.6 mm × 43.6 mm
Weight 4.75 kg
Operating Temp 0–50 °C
Warranty 5 years
